How to change the USB charging port of Samsung S21 Ultra 5G?

Publicado por Maria



How to change the USB charging port on the Samsung S21 Ultra 5G?

The Samsung Galaxy S21 Ultra 5G is a technological marvel, but like any device, it is not immune to wear and tear, especially in frequently used components like the charging port. If your S21 Ultra is not charging properly, the connection is intermittent, or the cable no longer fits snugly, you may need a replacement charging port. At iLevante.com, we not only offer the highest quality parts but also the information you need to understand the problem and, if you dare, fix it. Keep reading!

Understanding the Charging Port of your Samsung S21 Ultra 5G

The charging port is vital for your smartphone's daily life. It not only allows you to recharge the battery but also to transfer data and, in some cases, connect accessories.

Samsung S21 Ultra 5G Charging Port
Samsung S21 Ultra 5G Charging Port
Receive it on tomorrow friday 06 june
17.25€

Samsung S21 Ultra 5G Charging Port: Technical Specifications of the Samsung S21 Ultra 5G

The Samsung S21 Ultra 5G is equipped with a USB Type-C port. This modern standard offers several advantages:

  • USB Version: USB 3.2, ensuring high data transfer speeds.
  • Fast Charging: Supports USB Power Delivery (PD) 3.0, enabling super-fast charging up to 25W with the appropriate charger.
  • OTG (On-The-Go): Allows direct connection of other USB devices to the phone, such as USB drives, keyboards, or mice (with an adapter if needed).
  • Video Output: Can transmit video signals, for example, to connect the phone to a compatible monitor or TV (requires a USB-C to HDMI/DisplayPort cable or adapter).
  • Reversible Design: No need to worry about orientation when plugging in the cable.

It is important to note that the "charging port" as a replacement part for the Samsung S21 Ultra 5G is generally not just the metallic USB-C connector. It is a module or secondary board (daughterboard) that includes the USB-C port, the main microphone, and sometimes other components like FPC connectors for the mainboard or the SIM reader, depending on the exact revision of the part.

Compatible Charging Port References for Samsung S21 Ultra 5G

When searching for a replacement charging port for your S21 Ultra 5G, it is crucial to find the correct reference. The most common are:

  • GH96-14064A: Generally associated with model SM-G998U (U.S. version).
  • GH96-14201A: Generally associated with model SM-G998B (International/European version).

It is essential to verify the exact compatibility with your specific S21 Ultra 5G model before purchasing the part. At iLevante.com, we guide you to find the perfect Samsung S21 Ultra 5G charging connector replacement.

How Often Should the Charging Port Be Replaced?

There is no fixed interval for replacing the charging port. Its lifespan depends on several factors:

  • Frequency of use: The more you connect and disconnect the cable, the greater the physical wear.
  • Care when connecting: Forcing the cable, connecting it at incorrect angles, or using poor-quality cables can damage the internal pins.
  • Exposure to elements: Dust, pocket lint, and especially moisture can cause corrosion or blockages.

Generally, a USB-C port can withstand thousands of insertion cycles. You should consider replacing it only when you start experiencing persistent charging or data connection issues that are not resolved with cleaning or trying other cables/chargers.

All About the Samsung S21 Ultra 5G Battery ?

Along with the charging port, the battery is another essential component. Sometimes, "charging" issues may be confused with a faulty battery.

Specifications of the 5000mAh Battery for Samsung S21 Ultra 5G EB-BG998ABY

The S21 Ultra 5G features a powerful battery designed to keep up with demanding usage.

Compatible Battery References for Samsung S21 Ultra 5G

The main and most recommended reference for replacement is the original EB-BG998ABY. While third-party batteries exist, to ensure compatibility, safety, and optimal performance, choosing an original battery or one from a trusted supplier like iLevante.com is the best choice. Always look for an original Samsung S21 Ultra 5G battery or a high-quality equivalent.

Estimated Battery Life: Intensive vs. Light Use

The battery life of the S21 Ultra 5G is highly variable and depends significantly on the device's configuration (screen brightness, adaptive vs. fixed refresh rate), network coverage, active applications, and overall battery health.

  • Light Use: (Occasional web browsing, social media, messaging, some music). It could last more than a full day, exceeding 8-10 hours of screen-on time under optimal conditions.
  • Moderate/Mixed Use: (Combination of browsing, social media, video, music, some camera use). It is generally expected to last a full day, with about 6-8 hours of screen-on time.
  • Intensive Use: (Demanding 3D gaming, extended 4K/8K video recording, intensive GPS and mobile data use with the screen at maximum brightness). The duration may significantly reduce, possibly to 3.5-5 hours of screen-on time.

Note: These are estimates. Over time and with charge cycles, the battery's maximum capacity degrades, reducing these times.

When to Replace Your S21 Ultra's Battery?

Consider replacing your Samsung S21 Ultra 5G battery if you notice:

  • A drastic decrease in duration with the same usage pattern.
  • Unexpected shutdowns, even if the battery indicator shows charge.
  • The phone only works if connected to the charger.
  • The battery drains very quickly.
  • Physical swelling of the battery (this is dangerous and requires immediate attention).
  • The Samsung Members app (or similar) indicates that the battery's health is poor or needs replacement.

Diagnosis: Is it the Charging Port or the Battery? ?

Before rushing to buy spare parts, it is crucial to diagnose the problem correctly. A faulty Samsung S21 Ultra 5G charging port can exhibit symptoms similar to a depleted battery.

Common Symptoms of a Faulty Charging Port

  • The phone does not charge or the charging is intermittent (connects and disconnects).
  • Super Fast Charging does not activate, and it only charges slowly.
  • The USB cable has excessive slack in the port or disconnects easily.
  • You have to move or angle the cable for it to start charging.
  • The computer does not recognize the phone when connected via USB (data transfer issues).
  • There is visible physical damage inside the port (bent, broken, or corroded pins).
  • Moisture detected warnings even though the phone has not been wet recently (may indicate corrosion).

Steps to Diagnose Charging Issues

  1. Visual Inspection: With good lighting, inspect the inside of the USB-C port for lint, dirt, or damaged pins.
  2. Careful Cleaning: If you see dirt, try cleaning it with compressed air (short bursts) or a fine non-metallic tool (like a plastic or wooden toothpick), being very careful not to damage the pins. Never use metal objects!
  3. Test with Another Cable and Charger: Use an original Samsung USB-C cable and charger or a high-quality one that you know works properly with other devices. This rules out issues with the cable or power adapter.
  4. Try Wireless Charging: The S21 Ultra 5G supports Qi wireless charging. If the phone charges perfectly wirelessly but not via cable, the issue likely lies in the USB-C port.
  5. Restart the Phone: A simple restart can sometimes fix minor software glitches that could affect charging.
  6. Safe Mode: Boot the phone in Safe Mode to see if any third-party application is interfering. If it charges well in Safe Mode, the issue could be an app.
  7. Diagnosis with Samsung Members: The Samsung Members app has diagnostic tools that can help you check the battery status and cable charging connection.

Differentiating Charging Port Issues vs. Battery Issues

  • If wireless charging works but cable charging does not, the port is the main suspect.
  • If there are data transfer issues with the PC, it is almost certainly a port issue.
  • If the phone drains very quickly but charges normally (both via cable and wirelessly when it does), the battery is the most likely candidate for replacement.
  • If no charging method works and you've tested different cables/chargers, the issue could be more severe (battery, motherboard, or the port module itself).

Step-by-Step Guide: How to Replace the Charging Port of the Samsung S21 Ultra 5G

If you've confirmed that the charging port is the culprit and feel confident and skilled enough to perform a hardware repair, here is a general guide. This repair is of moderate to high difficulty.

Important! Before You Begin:

  • Risks: Mobile phone repair is delicate. There is a risk of damaging other components if not done carefully. You proceed at your own risk.
  • Warranty: Opening the device will likely void any remaining manufacturer warranty.
  • Skill: If you have no prior experience, consider seeking professional help. iLevante.com is not responsible for damages caused during an attempted repair.
  • Parts: Make sure you have the correct Samsung S21 Ultra 5G charging connector replacement and all necessary tools.
  • Water and Dust: It is highly likely that after the repair, water and dust resistance (IP certification) will be compromised or lost, even if new adhesives are used.
  • Discharge the Battery: For safety, discharge your phone's battery below 25% before starting to reduce the risk of fire if accidentally punctured.
  • Backup: Make a backup of all your important data!

Necessary Tools for Repair ??

  • Precision screwdriver kit (Phillips #00 or #000 are usually needed).
  • Heat gun or hairdryer (to soften the adhesive on the back cover).
  • Small suction cup.
  • Plastic opening picks (spudgers, opening picks).
  • Fine tweezers (preferably anti-static).
  • Anti-static wrist strap (ESD wrist strap).
  • Protective gloves and safety glasses.
  • New adhesive strips for the back cover (specific to S21 Ultra 5G).
  • SIM eject tool.

You can find many of these mobile repair toolkits at iLevante.com.

Device Preparation

  1. Turn off your Samsung S21 Ultra 5G completely.
  2. Remove the SIM card tray.
  3. Prepare a clean, well-lit, and organized workspace. Use a magnetic mat or containers to avoid losing tiny screws.

Disassembly Process (Summary Based on Official and Expert Guides)

The exact process may vary slightly, but the general steps are:

  1. Heat and Remove the Back Cover:
    • Using a heat gun or hairdryer (on low heat, carefully to avoid overheating), warm the edges of the back cover to soften the adhesive.
    • Place a suction cup near an edge (e.g., the bottom) and gently pull to create a small gap.
    • Insert a thin opening pick into the gap. Slide the pick along the edges to cut the adhesive. You may need to apply more heat and use multiple picks. Be very careful with any flex cables near the edges. The back cover is made of glass and is fragile.
  2. Remove the Wireless Charging Module and Antennas:
    • Once the back cover is removed, you will see a large protective cover that includes the wireless charging coil and several antennas (NFC, UWB).
    • This cover is secured by several Phillips screws. Remove them all carefully, noting their position (they may be of different lengths).
    • Disconnect the flex connectors for the wireless charging coil and antennas from the motherboard using a plastic tool.
    • Carefully lift and remove this module.
  3. Disconnect the Battery:
    • This is a crucial step before handling other components! Locate the battery connector on the motherboard and carefully disconnect it using a plastic tool (spudger).
  4. Access and Remove the Charging Port Module (Daughterboard):
    • The charging port module is located at the bottom of the phone.
    • It is generally connected to the motherboard via a main flex cable (interconnect cable) and possibly coaxial antenna cables.
    • Disconnect these cables from the charging port module and/or motherboard with a plastic tool. Be careful, they are delicate.
    • The charging port module will be secured by a few Phillips screws. Remove them.
    • Carefully lift and extract the defective charging port module. It may have slight adhesive underneath.

Replacing the Charging Port Module

  1. Place the new iLevante charging port module in its position, ensuring it fits correctly.
  2. Reattach the screws holding it in place.
  3. Carefully reconnect the main flex cable (interconnect) and any coaxial antenna cables to the new module and/or motherboard. Ensure the connectors are well-aligned before applying pressure.

Reassembly Process

Follow the disassembly steps in reverse order:

  1. Reconnect the Battery: Ensure the connector is properly aligned before pressing it.
  2. Reinstall the Wireless Charging/Antennas Module:
    • Reconnect its flex cables to the motherboard.
    • Place the module in position and screw it down. Make sure to use the correct screws for each hole.
  3. Clean and Apply New Adhesive to the Back Cover:
    • Thoroughly clean the remnants of the old adhesive from both the phone frame and the back cover.
    • Apply the new adhesive strips specific to the S21 Ultra 5G to the phone frame or back cover.
  4. Reattach the Back Cover:
    • Remove the protective films from the new adhesive.
    • Carefully align the back cover and press firmly along all edges to ensure a good seal. You can use clamps or place weight on top for a while to improve adhesion.
  5. Insert the SIM tray.
  6. Turn on the phone and thoroughly test the new charging port (normal charging, fast charging, data connection to PC) and the main microphone.

Precautions and Common Issues When Repairing the Charging Port ??

Even with a guide, problems can arise. Here are some common ones and how to prevent them:

List of Possible Complications

  • Damaging the glass back cover: It is very fragile. Apply heat evenly and do not use excessive force when prying.
  • Breaking flex cables: They are extremely delicate. Always use plastic tools to disconnect them and pull gently and perpendicularly to the connector. Never pull the cable itself.
  • Losing or mixing screws: They are tiny and often of different lengths. Organize them well. Using the wrong screw can damage the motherboard or screen.
  • Failing to reconnect the battery properly: This may result in the phone not powering on or having power issues.
  • Damaging the battery: Avoid puncturing or bending it. A damaged lithium battery can catch fire.
  • Forgetting a connector: This will result in some function not working (microphone, speaker, signal, etc.).
  • Poorly applied adhesive: The back cover may come loose or completely lose its (already compromised) water resistance.
  • Static damage (ESD): Use an anti-static wrist strap and work on an appropriate surface to protect sensitive electronic components.

Tips to Prevent Common Errors

  • Take your time: Rushing is the worst enemy in these repairs.
  • Document the process: Take pictures as you disassemble to remember where each piece and screw goes.
  • Work in a clean and organized environment.
  • If something doesn?t fit, don?t force it: Check for obstructions or if you are using the wrong part/screw.
  • Consult multiple guides: Watching specific repair videos for the S21 Ultra 5G can be very helpful.

Your Samsung S21 Ultra 5G, Good as New!

Replacing the USB-C charging port of your Samsung Galaxy S21 Ultra 5G is a feasible task if you have the right tools, a quality replacement part from iLevante.com, and a good dose of patience and care. Repairing your device not only saves you money but is also a more sustainable option. ??

If after reading this guide, the repair seems too complex, don?t worry! You can always seek professional technical service. But if you decide to embark on the adventure, at iLevante.com, we are here to support you with the best Samsung mobile spare parts and accessories.

Remember that a functional charging port and a healthy battery are key to enjoying your S21 Ultra 5G to the fullest. We hope this guide has been very useful to you! ?
